Bench Lathe KS-45
KS-45
JIAKUN KS-45 Bench CNC Lathe is designed for higher productivity and stable machining of medium-size precision parts. The rigid structure ensures reliable accuracy under continuous operation. With support for automated loading and bowl feeder systems, KS-45 enables efficient CNC turning within automated production lines.
| Category | Parameter | Specification (KS-45) | ||
|---|---|---|---|---|
| Spindle | Spindle Capacity with Collet Chuchucking Device | |||
| Round / Circular (nm) | 45 | |||
| Square / Quadrilateral (nm) | 32 | |||
| Hexagonal (nm) | 38 | |||
| Spindle Speed (r.p.m) | ||||
| Primary Rotation | 545/875/1407 | |||
| Secondary Rotation | 433/702/1104/1648 | |||
| Tool Slide | Max. Main Slide Travel (mm) | 138 | ||
| Max. front Cross Slide Travel (mm) | 90 | |||
| Adjustable Angles for Taper Turning of Front Slide | 360 | |||
| Tailstock | Max. Front Cross Slide Travel (mm) | 90 | ||
| Moss Taper | Morse NO.3 | |||
| Tail Spindle Chuck Select | JT6 | |||
| Max. Teavel of Tail Stock | 120 | |||
| Bed | Height of Centers (mm) | 168 | ||
| Length X Width X Height (mm) | 1100 x 520 x 1140 | |||
| Net Weight (kg) | 415 | |||
| Packing Detail: Length X width X Height (mm) | 1240 x 660 x 1230 | |||
| Machine Body / Housing | Driver Motor (hp) (r.p.m) | 1.5HP x 1425rpm (2HP) | ||
| V-Shaped Belt Length (inch) | A53(A43,A54) | |||
| Trace Length (mm) | 498 | |||
| Size of Cutters (inch) | 1212122026年1月2日 | |||
| Model of Spindle Chuck (inch) | 1/32-1/2 |
JIAKUN Bench Lathe is built with a rigid machine structure made from high-quality cast iron, fully tempered and stress-relieved to ensure long-term stability, precision, and reliable performance. The fully enclosed machining chamber provides effective waterproof protection and enhanced operational safety.
Designed for flexible automation, the machine can be upgraded with various automatic solutions, including oil bath, air bath, vibratory bowl feeder, and automatic loading and unloading systems. This makes it an ideal choice for high-efficiency and small-footprint automated production.
Case of Modifying Fully Automatic Specialized Machine
Jakun Machinery developed a customized desktop CNC lathe automation retrofit for full automatic watch bezel machining. The system adopts a pneumatic feeding control mechanism, integrating facing, chamfering, and cutting operations with a cycle time of only 1.5 seconds per piece. Supported by high-precision fixturing and a stable pneumatic system, it ensures excellent dimensional consistency, reliable performance, and outstanding productivity—offering an efficient automation solution for mass production of precision watch components.
Send us the drawing to get the appropriate configuration.
STEP / STP / SLDPRT / PRT / DWG/DXF files.
All files are secure and confidential.
