Horizontal Milling Machine KS-222A
KS-222A
JIAKUN KS-222A Horizontal Milling Machine is designed for larger workpieces requiring high precision and stable milling performance. The rigid structure supports heavy-duty cutting with reliable accuracy.
Optimized for automated production lines, KS-222A integrates automatic loading systems, demonstrating JIAKUN Machinery’s commitment to precision and productivity.
| Specifications | KS-222A |
|---|---|
| Bench L×W (mm) | 850×220 |
| Max.Y.Travel (mm) | 560 |
| Max.Y.Travel (mm) | 220 |
| Max.Z.Travel (mm) | 360 |
| T-Groove Working surface | |
| No.of Groove | 3 |
| Groove width | 14 |
| Groove Gap | 64 |
| Cutter Bore Diameter (mm) | 22/25.4/27 |
| Max.Cutter Outer Diameter (mm) | 255 |
| Max.Cutter Thickness (mm) | 80 |
| Spindle Speeds (rpm) | 300/2800 |
| Motor Power (kw) | 5.5/7.5 |
| Motor Speeds (rpm) | 1400 |
| V-shaped Belt length | double belt system |
| Machine Dimension(mm) | 2100×1750×2000 |
| Machine Weight (kg) | 1100 |
JIAKUN Horizontal Milling Machine is constructed with a high-rigidity machine body made from premium cast iron, fully tempered and stress-relieved to ensure long-term stability, accuracy, and reliable milling performance. The fully enclosed machining chamber provides effective waterproof protection and enhanced operational safety.
Designed for high-precision and continuous production, the machine supports various automated manufacturing solutions, including automatic loading and unloading systems and integration with robotic arms. This makes it suitable for efficient operation within modern CNC production lines.
Equipped with high-accuracy linear guideways and precision-ground ball screws, the horizontal milling machine delivers smooth motion, fast feed rates, and excellent surface quality. The optimized horizontal spindle layout ensures stable cutting, efficient chip evacuation, and consistent dimensional accuracy during heavy-duty milling operations.
With a flexible work holding configuration and a spacious machining area, JIAKUN Horizontal Milling Machine reflects JIAKUN Machinery’s pursuit of high precision, rigidity, and productivity for industrial milling applications.
